Drawings

FNCE BIM Library

Click below to lodge an enquiry for access

Brochure

Terms and Conditions

Technical Specifications

WARRANTY & COMPLIANCE

Registered Design Patent – Design No.202115442. Designs Act 2003
10 Year warranty on Standard Powdercoat paint finishes (Pearl White & Satin Black)
10 Year warranty on Aluminium
10 Year warranty on Fabrication
Aluminum Grade – Aluminum Temper – 6063/T5
Engineered balustrade design which satisfies AS1170.0, 1170.1

Designed in accordance with AS 1926.1 / 1926.2 – 2012 AS/NZS 1170, 1170,1 – 2002 & 1170.2 – 2021 AS/NZS 1664.1 – 1997 NCC 2022. Volumes 2 and 3 Testing & certification to AS 1926.1 – 2012 Swimming Pool Safety Standards Set Testing & certification to AS/NZS 1170 & 1170.1 – 2002

All Fence Products

  • 304 Grade Stainless Steel Barrell Bolts supplied to complete your project
  • Rails: Perimeter frame, legs and base plate: Solid flat bar
  • Balusters and Tube balusters – 2mm thick
  • Solid perimeter frame with full 5mm fillet welds
  • Hollow extruded balusters with full laser welds & Corner 5mm Plug Weld
  • FNCE products are available in 2 standard colours from the Interpon Commercial Grade D2525
    • Black Satin – Satin – YN167A
    • Pearl White – Gloss – YA075A
  • Custom colours and finishes can be ordered on request.

Slimline Fence Products

  • 50mm x 12mm Profile
  • 0.35Kn Load rating
  • Standardised panel sizes 3 base plate installation options
  • Panel weights: 5Kg – 14Kg
  • Comes in 2 standard colours
  • Solid perimeter frame with hollow balusters
  • 81mm baluster spacing
  • Slimline Standard and Core Hole Can be used for Balustrade up to Building classification A,B,E. Slimline Slab Edge can be used for Balustrade up to Buiding classification C3.

FNCE TUBE PRODUCTS

  • 50×12 Perimeter frame
  • 16mm x 2mm Tube balusters
  • Standardised Panel sizes with 2 base plate installation options
  • Panel weights: 4Kg – 12Kg
  • Comes in 2 Standard Colours
  • Solid Perimeter frame with hollow Tube balusters
  • 71mm Balusters Spacing
  • Can only be used for Pool Fencing Applications – NO balustrade

Barrier FNCE Products – Made to order

  • 65mm x 12mm Profile
  • 0.75Kn Load rating
  • Maximum panel size 1500mm W X 1350mm H
  • 4 base plate installation options
  • Panel weights: 10Kg – 20Kg
  • Comes in 2 standard colours
  • Solid perimeter frame with hollow balusters
  • 81mm baluster spacing
  • Barrier Standard and Full panels can be used for Balustrade up to Building classification C3
  • Barrier Slab Edge and Core Hole panels can be used for Balustrade up to Building classification C1, C2 and D

FNCE Barrier products are made to order. If you have a larger commercial or multi residential project, Our Barrier product can be customised to suit your project. Reach out to Tom to chat about your project.
